The physical platform behind H5-Flow and H5-APP - purpose-built hardware sized from a branch office up to a 10 Gbit/s datacenter core, with a dedicated forensic packet-capture tier for deeper investigation.
Designed specifically for network functions - not repurposed general compute hardware. This means better performance consistency and longer reliable operational life.
Enterprise reliability
Built to operate continuously in production environments, with hardware specifications suited to the demanding conditions of data center and enterprise network deployments.
Straightforward deployment
Appliance form factor simplifies deployment and replacement - no custom server builds or complex OS configuration required.
Direct distributor warranty and support
As the exclusive Baltic distributor, Sersor handles warranty claims directly on 1, 3, or 5-year support contracts, with a 1-hour response SLA and replacement hardware shipped within 5 working days - no overseas support center to deal with.
H5-Appliance Hardware at a Glance
10 Gbit/s
Peak throughput on the H5-700 and H5-700cc models - 1.8 million packets per second
48 TB
Dedicated RAID storage for full packet capture on the H5-700cc model
1/3/5-yr
Support contract terms available, with English and French technical assistance
5 days
Replacement hardware ships within 5 working days of an RMA ticket
H5-Appliance Hardware Models
H5-200
The H5-200 is the entry point into the H5-Appliance hardware range: a compact 1U appliance built for a branch office or a smaller site, with two acquisition ports, 250 GB of onboard storage for statistics, and a continuous rolling buffer for deep packet analysis built in.
It runs the same H5-Flow and H5-APP software as the larger models, so a smaller site gets the same monitoring capability, sized down rather than left out.
The H5-700 is the datacenter-class model: a 2U appliance with 10 Gigabit SFP+ acquisition ports rated to 1.8 million packets per second, redundant power supplies, and IPMI for remote management - built to sit at a network core or datacenter edge without becoming a single point of failure itself.
With 1 TB of onboard storage and support for 2,000 monitored objects, it is sized for a scale of traffic and object count a branch-level H5-200 is not.
2U rack, 10 Gbit/s (1.8M pps) throughput
2x 10G SFP+ plus 2x GigE acquisition ports, redundant power supplies
2,000 monitored objects, 500 business flows, 1,000 VLANs
Best for: Datacenter cores, network edges, and any deployment where both throughput and hardware redundancy matter.
The H5-700cc adds what the standard models do not have: 48 TB of dedicated, RAID-protected rolling-buffer storage reserved entirely for full packet capture, so when an incident needs deeper evidence than flow statistics can provide, the actual packets are already there to pull in pcap format - no separate packet-capture tool to deploy after the fact.
Same 10 Gbit/s throughput class as the H5-700, in a 4U chassis sized for the extra drive capacity.
4U rack, 10 Gbit/s (1.8M pps) throughput
48 TB dedicated RAID storage for full packet capture (cyclic capture)
1,500 monitored objects, 500 business flows, 1,000 VLANs
Best for: Security teams and incident responders who need forensic-grade packet history on hand, not just flow-level statistics, for post-incident investigation.
Running more than one H5-Appliance across multiple sites? H5-CPR aggregates real-time dashboards and configuration management across up to 50 connected appliances from a single console, so you are not logging into each site separately to see what is happening network-wide.
Frequently Asked Questions
H5-Appliance hardware ranges from the compact H5-200 (1U, sized for a branch office) up to the H5-700 (2U, 10 Gbit/s, datacenter-class) and the H5-700cc, which adds 48 TB of dedicated storage for full packet capture. As the exclusive distributor, Sersor maintains current availability and can help match the right model to your traffic volume and site count.
H5 Network offers 1, 3, or 5-year support contracts across the H5-Appliance, H5-Flow, and H5-CPR product lines, including English and French technical assistance with a 1-hour response SLA during business hours, and replacement hardware shipped within 5 working days of an RMA ticket. As your exclusive Baltic distributor, Sersor handles the relationship on your behalf - you deal with us, not an overseas support center.
Sersor is the exclusive H5 Network distributor for Latvia, Lithuania, and Estonia. We are the only authorized source for genuine H5-Appliance hardware with proper warranty coverage and vendor support in these countries.
Yes - H5-CPR aggregates real-time dashboards and centralizes configuration deployment across up to 50 connected appliances, so a multi-site deployment can be monitored and managed from a single console instead of logging into each appliance separately.
H5-Appliance is the physical hardware platform - the H5-200, H5-700, and H5-700cc models. H5-Flow (NetFlow/sFlow/IPFIX flow analysis) and H5-APP (deep packet and application performance monitoring) are the monitoring solutions that run on that hardware. In practice, most customers choose the H5-Appliance hardware tier first, based on throughput and site count, then decide which monitoring solution - or both - to run on it.
Get in touch
Request H5-Appliance Pricing and Specifications
As the exclusive distributor, we can provide current specifications, pricing, and availability for all H5-Appliance models. We will respond within one business day.
